Standard Equipment:
- Welded legs
- Bottom outlet with ball valve ¾"
- Racking outlet with ball valve ¾"
- Tap ½"
- Sample tap ½"
- Floating lid
- Dust cover
- Ladder support
Dimensions:
- Volume: 3300 liters
- Diameter (D): 1333 mm
- Total height (H): 2400 mm
- Cylindrical part height (h1): 2000 mm
- Height from ground to bottom tap (h2): 400 mm
- Lid/Mechanism height (h3): 1000 mm
Materials:
- Stainless Steel AISI 304 (1.4301)
- Mirror polished inside (BA/IIId)
- Circle polished outside
Options (Available Separately):
- Ball or butterfly valves – DN, WG, garolla, TC, macon
- Floating lid with gasket, air pump and vent valve
- Vent valve
- Screw cap with vent valve
- Lifting arm for floating lid
- Hand winch
- Level gauge DN15 - Ø16 mm
